Strut Channel | Know Types, Uses, Application & More
In the United Arab Emirates, the construction industry has come a long way from basic scaffolding to modern infrastructure. Furthermore, one of the key factors that significantly affected the construction industry is the strut channel. Furthermore, strut channels are also known as channel strut, channel, unistrut, and a simple “strut” gives a secure and strong structure for the building, whether it’s in the commercial or residential industry.
Additionally, the strut channel in UAE is adjustable and does not require welding for hassle-free use. Similarly, strut channels are first utilized for framework and structural support for mechanical, plumbing, and wiring components for HVAC (Heating, Ventilation, and Air Conditioning) and electrical applications. Furthermore, in this comprehensive blog, we will discuss its various types, applications, vital uses, and more. Therefore, strut channels are one of the best ways to bring construction into modern infrastructure.
What is a Strut Channel?
Strut channel in UAE is a C-shaped or U-shaped metal & steel channel applied as an electrical or mechanical support system for use across diverse sectors. In addition, the strut channel design has an inward-conforming lip structure on the broad open side of the channel to accommodate infinite fasteners such as brackets, bolts, and nuts. Additionally, strut channels are usually manufactured from durable and sustainable raw materials, such as aluminum, mild steel, or stainless steel. Likewise, their modern and sleek design allows you to form any structure into your desired shape without drilling or welding. Therefore, this feature makes them an ideal choice for permanent and temporary installations.
Nevertheless, some individuals call strut channels “Unistrut Channel,” a very popular brand that made the product well-known, but numerous Unistrut manufacturers in UAE make the product with other names. Still, when experts speak about what a strut channel is, they’re typically talking about the same globally accepted support system. Moreover, the idea is straightforward: sturdy, functional, simple-to-install metal channels holding up equipment elements from solar systems to shelving units. Once you grasp what a strut channel is, you’ll begin noticing it everywhere in ceilings, roof structures, walls, and even outside.
Standard Technical Configuration of Struct Channels
| Specification | Details |
|---|---|
| Material | Mild Steel (MS), Stainless Steel (SS), Aluminum, Galvanized Steel |
| Standard Sizes (Width × Height) | 41 × 41 mm (standard), 41 × 21 mm, 41 × 62 mm, 41 × 82 mm, custom options |
| Thickness (Gauge) | 1.5 mm, 2.0 mm, 2.5 mm, 3.0 mm |
| Length | 3 meters, 6 meters (standard) |
| Slot Type | Slotted, Unslotted (Plain), Half-Slot |
| Slot Dimensions | 14 × 28 mm (oval), 18 × 28 mm, or customized |
| Surface Finish | Pre-Galvanized, Hot-Dip Galvanized, Powder-Coated, Painted, Stainless Finish |
| Load Capacity | Varies with size & gauge (light, medium, heavy-duty) |
| Standards | BS 6946, ASTM A653, DIN EN 10346 |
| Accessories | Brackets, Nuts, Bolts, Washers, Connectors, End Caps |
| Applications | Electrical conduit support, HVAC duct support, Cable tray systems, Pipe supports, Solar mounting structures |
What are the Different Types of Strut Channel?
Strut channel in UAE comes in a wide variety of shapes and sizes to accommodate multiple load needs, space constraints, and mounting technical specifications. Furthermore, here we have mentioned the most common types of strut channels that every individual should know before buying them from the leading manufacturers.
1. C Channel
A C Channel in UAE, or structural channel, is a metal item with a cross-sectional shape that looks like the letter “C”. It is flat in the back (web) and extends outward in two flanges. Still, the most distinguishing characteristic is that the flanges are tapered, i.e., they are slightly sloping or angled as opposed to being perfectly parallel.
Moreover, these channels are produced using hot rolling, which forms robust, hardy profiles meant for structural use. Because of their high strength and standardization, C channels have a broad application in construction, frames of heavy equipment, and industrial work.
Key Features:
- Pointy Flanges
- Hot-Rolled Manufacturing
- High Structural Stability
- Generally Used In Beams, Supports, and Frames
Applications:
- Steel Building Structures
- Support Beams in Industrial Applications
- Crane Rail Systems
Technical Configuration of C Channel
| Property | Description |
|---|---|
| Shape | Cross-section resembles the letter “C” with one side open (two parallel flanges connected by a web). |
| Material | Mild Steel (MS), Stainless Steel (SS), Aluminum, Galvanized Steel, etc. |
| Standards / Codes | IS 808:1989 (Indian Standard), ASTM A36 / A992 (USA), EN 10025 (Europe), BS 4 (UK). |
| Available Sizes (Depth) | Commonly ranges from 75 mm to 400 mm (3″ to 16″). |
| Width of Flange | Typically 35 mm to 100 mm, depending on depth. |
| Thickness (t) | Usually 4 mm to 12 mm (varies with size & load capacity). |
| Length | Standard lengths: 6 meters, 9 meters, 12 meters (custom cut available). |
| Weight per Meter | Varies by size, e.g., 5.3 kg/m (C75x40x4.8) to 58 kg/m (C400x100x12). |
| Sectional Properties | Moment of Inertia (I), Section Modulus (Z), Radius of Gyration (r) — depend on size and thickness. |
| Surface Finish | Hot-rolled, cold-rolled, galvanized, or painted. |
| Applications | Structural framing, purlins, trusses, support beams, railings, machine frames, solar panel mounting, vehicle chassis, etc. |
2. U Channel
A U Channel in UAE is a second form of metal channel that resembles the letter “U” in its cross-sectional shape. In contrast to the C channel, the flanges of a U channel are parallel to one another, so they do not taper or slope. However, this makes the U channel more symmetrical in appearance and easier to align with other flat surfaces.
Moreover, U channels are typically fabricated via cold forming processes, including extrusion or bending sheet metal. The method of manufacturing provides tighter dimensions and neater edges. Still, it tends to create a more lightweight product that is less ideal for heavy structural uses than for hot-rolled C channels.
Key Features:
- Same Structure Flanges In Parallel
- Cold-Extruded or Formed
- Lightweight and Seamless Working Profile
- Ideal For Non-Structural and Decorative Uses
Applications:
- Doors and Windows Frames
- Edging and Trimming from enclosures or panels
- Light-Duty Framing Systems
Technical Configuration of U Channel
| Parameter | Details |
|---|---|
| Shape | U-shaped cross-section (resembles the letter “U” or “C”) |
| Material | Mild Steel (MS), Stainless Steel (SS), Aluminum, Galvanized Steel, or other alloys |
| Standards | IS 808 (Indian Standard), ASTM A36 / A572 (American), EN 10025 (European) |
| Sizes Available | Depth (h): 75 mm – 400 mm Flange width (b): 40 mm – 100 mm Thickness (t): 5 mm – 15 mm (varies by standard) |
| Length | Standard supply length: 6 m / 12 m (custom cut also available) |
| Designation | Noted as “U” or “C” followed by depth × flange × weight (e.g., U 200 × 75 × 25) |
| Tolerance | As per IS 1852 / ASTM A6 (dimension & weight tolerances allowed) |
| Surface Finish | Hot Rolled (HR), Cold Formed (CF), Galvanized, Powder Coated, Painted |
| Weight Range | Approx. 5 kg/m – 60 kg/m (depends on size & thickness) |
| Applications | Structural frames, support channels, racking systems, purlins, machinery frames, guide rails, cable trays |
What are the Common Uses of Strut Channel?
In this particular section, comprehending the use of U or C Channel in UAE is imperative for increasing efficiency and decreasing structural failure in your construction projects, regardless of the industry. Nevertheless, strut channels are one of the go-to solutions for all contractors and engineers when they require durable, versatile, sustainable, and fast support systems. Likewise, here are some of the most standard strut channel uses that every individual should know across different domains.
- Building and factory electrical conduit mounting systems
- HVAC duct and piping support systems on rooftops and indoors
- Plumbing system frames for supporting pipes and valves
- Solar panel racking systems in rooftop as well as ground-mounted installations
- Industrial shelving, storage racks, and equipment mounts
- Panel, device, or sign mounting in commercial environments
- Temporary structures and modular installations’ framework
- DIY construction tailored to a person’s specifications, such as workbenches or garage shelving
Some Vital Advantages of Strut Channels
In this particular section, we have mentioned some imperative benefits of the strut channel in UAE, including:
- Strength and Durability
- Versatility and Adaptability
- Cost-Effective Solution
- Accessibility and Maintenance
- Compliance with Standards
- Collaboration and Consultation
Applications of Strut Channels in Different Industries
Here are the top three applications of strut channels that you can get from one of the best C channel suppliers in UAE:
1. Electrical Installations
Strut Channel Framing Systems are extensively applied in electrical installations to ensure a secure structure for the installation of cables, pipes, tubes, and wiring. Furthermore, these systems facilitate the safe and efficient operation of the electrical services, reducing the risk of damage, interference, or accidents. In addition, they provide supportive security, avoiding sagging or stress on electrical elements and ensuring efficient power distribution.
2. Mechanical Support
The strut channel in UAE is best suited to offer mechanical support for different industrial uses. Furthermore, they are widely used to hold up HVAC systems, pipes, and ducts, providing stability and structural support. Likewise, the rugged infrastructure offered by such systems guarantees that mechanical equipment is appropriately aligned and held firmly, maximising system performance and avoiding problems.
3. Power Generation
Strut channel framing systems play a vital role in supporting heavy equipment and electrical systems in power generation facilities. They provide a rugged and sturdy frame that ensures safe and efficient operation of critical infrastructure. By U Channel in UAE, they provide stability and weight-carrying capacity, enabling the support of heavy equipment and the distribution of electrical services.
It’s Time To Wrap Things Up!
Strut channels are imperative in industrial construction, whether it’s commercial or residential. Therefore, when it comes to finding the best unistrut manufacturers in UAE, look no further than Metal n Machine. We offer a complete strut metal structure framework system that is applicable in several industries. Moreover, our strut channels are manufactured to meet all over the world’s standards, including the cantilever arms, fixings, different channels, beam clamps, and brackets.
Likewise, it provides versatile, sustainable, and durable support structures. Therefore, our team of skilled and experienced professionals offers top-quality strut channels according to your needs and preferences. So, what are you waiting for? Connect with us today!
